CE ISO SGS OEM TL1600T 1600kg Telescopic Boom Articulated Front End Compact Small Mini Telescopic Wheel Loader with Euro5 engine Grab
Weihai Titan Heavy Machinery Co., Ltd.- After-sales Service:24-hour online service
- Warranty:One year
- Certification:TUV, UL, ISO, RoHS, CE
- Condition:New
- Rated Load:<1t
- Transmission:Hydraulic - Mechanical
Base Info
- Model NO.:TL1600T
- Load and Unload Mode:Front Discharge
- Walking Mode:Wheeled
- Type:Small Loader
- Operating Weight:1600kg
- Bucket Capacity:0.6cbm
- Engine:Yunnei
- Rated Power:42kw
- Max. Dumping Height:3777mm
- Rated Speed:2400r,Min
- Drive Means:4 Wheel Drive
- Lifting Height:4232mm
- Overall Height:2619mm
- Min. Turning Radius:4145mm
- Overall Width:1700mm
- Wheelbase:2317mm
- Overall Length:5832mm
- Tyre:23.5,70,16
- Bucket Width:1300mm
- Transport Package:Nude in Container
- Specification:4700*1600*2550
- Trademark:TITAN
- Origin:China
- HS Code:84295100
- Production Capacity:1000,Year
Description
1.0 Engine Details1) Model Yunnei 2) Engine Type In-line arrangement,water-cooled,four-cycle diesel engine 3) Rated Power 42KW 4) Rated Speed 2400r/min(rpm) 5) Fuel Consumption ration in standard working condition 230g/kw·h 2.0 Tranmission System 1) Type Fixed-spindle power shift 2) Shift Gear Control Oil Pressure 1.2-1.6MPA 3) Rated Input Speed 2500(rpm) 4)Max. Breakout Force 36.8KN 3.0 Bucket 1) Bucket Capacity 0.6cbm 2) Bucket Width 2000mm 3) Bucket Type Heavy-duty bolt on teeth 4) Rated Load 1600kg 5) Operating Weight 4300kg 4.0 Overall Dimensions 1) Overall Length(bucket on the ground) 5832mm 2) Overrall Heigjt 2619mm 3) Dumping Height 3777mm 4) Lifting Height 4232mm 5) Overall Width 1700mm 5.0 Operating Specifications 1) Steering System Articulared Frame with Hydraulic Power Steering 2) Min. Turning Radius 2400mm 3) Max. Turning Radius 4245mm 4) Driving System Hydraulic Converter 6.0 Brake System 1) Service Brake Four Wheel Hydraulic Spread-shoed Brake 2) Parking Brake Hand Operated 7.0 Tyre 23.5/70-16 Tires / Ag Tires 8.0 Wheelbase 2317mm
FAQ
Q:Why choose Titan?
We sell every machine at a fair price.As our production increases,we are getting much support from the purchase source of raw meterial.
We leave the maximum profit to customer.
1) Titan: an experienced loader manufacturer with over 11 years.
2) Titan team: customers-focused,you'll get reply within 5 minutes.
3)Titan: premium quality with reasonable price.
4) Titan: CE,BV,SGS,ROPS and FOPS,ISO9001:2008 varified.
The quality control is not an empty word in TITAN.Our products are tested and granted CE cetificate.
Q:What is Titan warranty?
TITAN has a professional sales and after-service team.We are trying our best to make a good service for every customer.
1) Titan after-sales: life-long, meantime offer one year and one month warranty.
2) Titan proposal: order some wearing parts with loader for easy maintenance.
Q:What about Titan delivery term?
TITAN Transport packsging team helps our customer to transport their machine in safe and secure way without any damage.
10-20 days after down payment received.
Q:What about the payment term?
30% advance payment,70% balance by T/T.
