Multifunctional Wheel Front End Loader EPA with 1cbm Bucket for Sale
Shandong Beijun Heavy Industry Co., Ltd.- Certification：CE
- Condition：New
- Rated Load：1-3t
- Transmission：Hydraulic
- Load and Unload Mode：Front Discharge
- Walking Mode：Wheeled
Base Info
- Type：Small Loader
- Rated Bucket Capacity：0.7m³
- Engine Model：Xinchai A498bt
- Maximum Dump Reach：950 mm
- Minimum Turning Radius：4900mm
- Wheel Base：2150mm
- Wheel Tread：1500mm
- Overall Dimension(Lxwxh)：5270X1850X2710mm
- Transport Package：Wooden Packaging
- Specification：5270x1850x2710mm
- Trademark：Beijun
- Origin：Shandong
- Production Capacity：1000 Set a Month
Description
SPECIFICATIONS OF 926 WHEEL LOADERDescriptions Specifications Rated Bucket Capacity 1.0m³ Rated Loading Capacity 2000kg Overall Weight 5700kg Maximum Breakout Force 60kN Maximum Tractive Force 50kN Maximum Dump Height 2800mm Maximum Dump Reach 1050 mm Minimum Turning Radius 5070mm Wheel Base 2335mm Wheel Tread 1500mm Overall Dimension(LxWxH) 5870x1940x2830mm Engine Engine Model YITUO LR4B3-24 / Cummins Engine Engine Type Vertical,in-line,Water cooled,4-Stroke diesel engine Rated Power 60kW Rated Revolution 2400rpm Transmission System Torque Converter YJ280 Gearbox ZL20 Gear Shift 2forward shift,2reverse shift Maximum Speed 24km/h Tyre 16/70-20
