• Model NO.：SE135
• Drive Type：Internal Combustion Drive
• Bucket Capacity：0.5~1.0m³
• Size：Large-Scale
• Certification：CE, ISO9001: 2000
• Condition：New
• Transport Package：Nude Packing
• Specification：13.5T
• Trademark：shantui
• Origin：China
• HS Code：8429521200
• Production Capacity：10000,Months

SE135 Engine Engine model QSF 3.8TRated power86kw/2200rpmMax.torque470N·M/1100~1700rpmDisplacement3.76 LEmission   standardTier 3Operation   Range Operating   weight13500 kgMax. digging   height8495 mmMax. dumping   height6060 mmMax. digging   depth5490 mmMax. vertical   digging depth4625 mmMax. digging   reach8300 mmMin. swing   radius2445 mmDimensions Overall   length7860 mmOverall width2500 mmOverall   height2855 mmTail swing   radius2380 mmMin. ground   clearance425 mmCounterweight   ground clearance915 mmUndercarriage/Working   Device Std. track   shoe width500 mmBucket   capacity0.55 m³Carrier   roller(per side)1Track   roller(per side)7Track gauge2000 mmBoom length4600 mmArm length2500 mmPerformance Travel speed3.25/5.2 km/hGradeability35°Ground   pressure41.5 kPaTractive   force118 kNBucket   digging force97 kNArm digging   force70 kNService   Refill Capacities Fuel tank220 LEngine   coolant20 LEngine oil12 LHydraulic   tank177/205 LHydraulic   System TypeNegative flow   Hydraulic system with Variable Displacement Piston PumpPump flow2X130L/minSwing System Swing speed0-11.3r/min
