Diesel Portable Concrete Mixer Mobile Automatic Loading Concrete Mixer Pump Truck 1~6cbm
Shandong Davoo Machinery Co., Ltd.- Type：Concrete Mixer
- Shotcrete Type：Wet
- Machining Process：Hydraulic
- Structure：Cylinder Type
- Productivity：25m²,h
- Condition：New
Base Info
- Color：White
- Trademark：shanding
- Origin：China
- HS Code：8705400000
- Production Capacity：4000set,Year
Description
The main performance paprameters of the chassis and the main performance parameters of the engineEngine type/displacement L CF4B68G-Z-13B2/CF4C100T-Z-13B2 Model Straight injection type four stroke water cooled supercharged diesel engine Rated power kw/r/min 55KW/2400 78KW/2400 Max torque N.m/r/min 255/1500-1800 380/1500-1800 Max running speed km/h 24 Min steering radius mm 5000 Climbing capacity % 26 Tire 23.5/70-16 Driving way 4×4 Weight kg 4580 Maximum load capacity kg 2800 Whole machinery weight kg 7380 Overall size(L*W*H) mm 6100*1850*3000
