• Model NO.：40 ton material handler machine
• Size：Small-Scale
• Certification：CE, ISO9001: 2000
• Condition：New
• Grab Type 1：Orange-Peel Grab
• Grab Type 2：Clamshell Grab
• Grab Type 3：Magnet Plates
• Grab Type 4：Mobile Shear Types
• Grab Type 5：Log,Timer Grab
• Transport Package：Bulk
• Specification：8500kg
• Trademark：YICHAO
• Origin：China
• HS Code：8429521200
• Production Capacity：1000 Pieces,Year

ItemunitYGLZ90Operating weightkg8300Overall sizemm7250*2180*2950EngineModelWeichaiZGBZG1Powerkw59Speedrpm2400Max torquen.m209Fuel comsumptiong/kw.h≤251Fuel tank volumeL140Hydraulic systemMain pumpRexrothAP3VO95Rated pressureMpa30Rated flowL/min190Main valveRexrothVS18LUDVHydraulic oil tank volumeL160Hydraulic motorSwing motorRexrothMA45WOLWalking motormodelA2F80Performance digitalSwing speedrpm10walking speedHigh speedKm/h20Low speedKm/h3.9Max torquekn53Gradeability°25Cabin1380*930*1600Swing supportQBD800Axle2080Tyre825-16CylinderImported sealsHydraulic hoseManuliGaugesColored gauges

Item	Unit	FMWG90
Upper width	mm	2170
Tail swing radius	mm	2000
Counter balance clearance	mm	1095
Min clearance	mm	250
wheel base	mm	1670
track base	mm	2300
Arm length	mm	3600
Stick length	mm	1800
Grapple volume	m3	1
Total width	mm	2720
Grapple size
Item	Unit	FMWG90
Sell weight	kg	336
Overall size(open)	mm	1520*710*1475
Working pressure	Mpa	30
Max open size	mm	1436
Min close size	mm	175
Rotation angle	°	360 degree
Max unloading height	mm	4730
Radius at max unloading height	mm	3320
Max grapple radius	mm	7580
Max grapple radius at ground	mm	7375
Max grapple depth	mm	4535
Radius at max grapple depth	mm	2919
