• Condition：New
• Color：Yellow
• Transport Package：Nude Package
• Trademark：SHANTUI
• Origin：Shandong, China

PRODUCTSD13 PERFORMANCE PARAMETERSOperatiing   Weight (kg)13700Rated horsepower (kw/hp)105/130Minimum turning radius (mm)3880Ground pressure (kpa)53.8ENGINEModelSC8D143G2B1EmissionChina   IITypeIn-line,direct   injection,water cooled,4-cycles,turbochargedNo.of cylinders×Bore×stroke (mm×mm)6×114×135Piston displacement (L)8.27Horsepower/rpm (kw/rpm)105/1900Maximum torque (N.m/r/min)674/1300DIMENSIONSLength(mm)4492Width(mm)3185Height(mm)2950TRAVELING PERFORMANCEForward/Reverse(km/h)F1:0-3.2   F2:0-5.9 F3:0-9.8 R1:0-3.9  R2:0-7.1   R3:0-11.9Gradeability(deg)30Clearance(mm)320TRANSMISSIONTorque   convertor 3-element, single stage, 1-phaseGear boxPlanetary   gear and powershift transmission, hydraulically actuated, forced lubricationMain driveSpiral   bevel gear, single-stage speed reduction, splash lubricationSteering clutchWet   multiple disc,coned disc spring loaded, hydraulically actuated, hand   operated,interconnected with steering brakeBrake Wet, contracting band,foot operated with   hydraulic boosterFinal driver spur gear,double reduction ,splash   lubricationUNDERCARRIAGESuspensionSwing   type of sprayed beam,suspended structure of equalizer barTrack gauge (mm)1880Shoe width (mm)460Track length on ground (mm)2365Number of shoes (each side)38Pitch (mm)190Carrier rollers (each side)2Track rollers (each side)6WORKING HYDRAULIC SYSTEMPressure(Mpa)14Working pumpGear   pumpValveMulti-way   valveBore of blade lift cylinder (mm)φ90Bore of blade tilt cylinder (mm)φ160TANK CAPACITYFuel   tank capacity (L)300Working hydraulic tank capacity (L)70WORKING EQUIPMENTBlade   width (mm)3185Blade height (mm)1090Blade capacity (m³)3.7
