China Manufacturer Grader 210HP Motor Grader Sg21-3 Mini Motor Grader in Africa Popular
Evangel Industrial (Shanghai) Co., Ltd.- Warranty：1 Years
- Certification：CE
- Condition：New
- Application：Railway, Mine, Farmland, Highway
- Transmission：Hydraulic - Mechanical
- Walking Mode：Wheeled
Base Info
- Model NO.：SG21
- Type：Medium-sized Grader
- Transport Package：Nude Package
- Origin：China
- Production Capacity：100units,Month
Description
Engine
Engine model
6BTAA5.9-C180
Rated power/speed
132 kW/2200 rpm
Engine type
In-line, water-cooled, 4-cycle, direct injection, turbocharged
Number of cylinders
6(102X120mm)
Piston displacement
5.9L
Maximum torque/speed
770 N·m/1500 rpm
Minimum fuel consumption
206 g/kW·h
travel speed
Transmission and torque converter: Electronic controlled transmission
Gear
1st
2nd
3rd
4th
5th
6th
Forward
0~5.4 km/h
0~9.3 km/h
0~12.2 km/h
0~20.7km/h
0~25.6 km/h
0~39.7 km/h
Reverse
0~5.4 km/h
0~12.2 km/h
0~25.6 km/h
TRAVEL
Tire Type
17.5-25PR12
Steering system
Max. steering angle of front wheel
±45°
Max. tilting angle of front wheel
±17°
Max. oscillating angle of front axle
±15°
Steering angle of frame
±25°
Max. oscillating angle of rear axle
±15°
Min. turning radius
7800 mm
Operation weight
Operating weight (standard configuration)
16200 kg
Front axle load
4800 kg
Rear axle load
11400 kg
Blade
Blade length
3660/3965 mm
Blade height
635 mm
Blade rotational angle
360°
Cutting angle adjustment range
44~91°
Maximum cutting depth
500 mm
Cutting force per dozing
24.47 kN/m
Maximum lift above ground
440 mm
Maximum blade lateral extension (left/right)
1900/1950 mm
