GENERAL SPECIFICATION | Operating weight | 10300kg |
Related loading | 3000kg |
Bucket capacity | 1.7cbm |
Maximum lifting force | 105kN |
Static tipping load(full turn) | 6000kg |
Dumping height(Extended/Long) | 3057/3200mm |
Dumping reach(Extended/Long) | 906/886mm |
ENGINE | Engine model | Weichai WP6G125E201 |
Type | In-line, water-cooled, 6-cylinder, direct injection, turbocharged |
Rated power | 92kW |
Rated speed | 2000rpm |
Displacement | 6.75L |
Maximum torque | 540N-m |
Minimum fuel consumption | 217g/kW-h |
AXLES AND FINAL DRIVES | DRIVE SYSTEM | Four-wheel drive |
Gradeability | 30° |
Maximum traction | 110kN |
Service brakes | Air over hydralic disc brakes on 4 wheels |
Parking brake | Manual parking brake |
Type | Articulated type. full-hydraulic power steering |
Maximum steering angle | 36° each direction |
The conter of outside tire | 5325mm |
The center of outside bucket | 5920mm |
Type | 17.5-25 12PR |
Pattern level | L3 |
Center distance of tires | 1856mm |
Wheel base | 2700mm |
