Tractor Fit with Pallet Fork / Fork Lift (LZ404, TZ04D)
Gooler International Group Co., Ltd.- Type：Wheel Excavator
- Engine Power：40HP, 45HP,50HP,55HP
- Hydraulic System：Hydraulic Steering
- Clutch：Dual-Stage Type
- Hydraulic Output Valve：2-Way (Optional)
- Overal Size：3835x1620x2220
Base Info
- Model NO.：LZ404, TZ04D
- Gear Shift：8f+4r,8f+8r(Optional)
- Transport Package：Irong Crate Packing or Naked Drive Inside
- Specification：High
- Trademark：ENFLY
- Origin：Shandong
- HS Code：8701901190
- Production Capacity：10, 000sets,Year
Description
| Luzhong 404-554 Tractors Main Technical Specifications | ||||||
| Model | LZ404 | LZ454 | LZ484 | LZ554 | ||
| Type | 4WD Wheeled Type | |||||
| (mm)Dimensions of Tractor | Length (to front ballast) | 3835 | ||||
| Width | 1620 | |||||
| Height (to the exhaust vent) | 2220 | 2135 | ||||
| Tread | Front Wheel | 1280 | ||||
| Rear Wheel | 1300 Fixed or 1200~1500 Adjusted | |||||
| Axle Base | 2030 | |||||
| Min. Ground Clearance | 325 | |||||
| Structure weight (kg) | 1665 | 1734 | ||||
|
Ballast weight (kg) |
Front ballast | 140 | 168 | |||
| Rear ballast | 200 | 300 | ||||
| Rated traction force (kg) | 1100 | 1130 | 1140 | 1150 | ||
| EPA Engine | Model | 3105/490 | 495 | 495/498 | 498/4100 | |
| Type | Vertical, 4-Cylinder, Water Cooled and 4-stroke | |||||
| Rated Power(kw) | 29.4 | 33 | 35.2 | 36.7 | ||
| Rated speed (r/min) | 2400 | |||||
| Fuel | Diesel | |||||
| Tyre | Front Wheel | 8.3-20 | ||||
| Rear Wheel | 12.4-28 | |||||
| Clutch | Dual-stage clutch | |||||
| Steering | power steering | |||||
| Transmission Type | 8+4 or 8+8 with shuttle gearshift or (8+4)× 2 with creeper shift | |||||
| Suspension Type | 3-point links | |||||
| PTO | Type and Rev | Semi-independent Type 540/1000 | ||||
| Spline Size | F35 Rectangle Spline with 6 teeth | |||||
| Structure and specification are subject to change without notice. | ||||||
