- Model NO.:719H
- Transport Package:Nude Package
Overall Dimension | |
1 Length*Width*Height(To the top of the cab) | 9385*2600*3370mm |
4 Wheel base | 6150mm |
5 Tread | 2120(mm) |
Main Technical Specification | |
1 Operating weight | 15800kg |
2 Blade length | 4268mm |
3 Blade height | 550mm |
4 Blade width | 16mm |
5 Max lifting height | 450mm |
6 Max grading depth | 535mm |
7 Min. turning radius | 7400mm |
8 Pivot angle frame | ±26° |
9 Max turning angle(front wheel) | ±49° |
10 Oscillating angle of front axle | 32° |
11 Front axle center grond clearance | 610mm |
12 Traveling speed(Km/h) | 6 forward and 3 reverse |
Diesel engine | |
1 Model | USA engine 6CTAA8.3-C185 (TIER2) |
2 Type | Direct injection. Turbocharged. |
3 Rated output | 138kW |
4 Inter-bore of cylinder/Stroke | 114/135 (mm) |
5 Total exhaust of cylinder | 8.3(L) |
6 Power of start motor | 7.5 (kW) |
7 Voltage of starting motor | 24(V) |
8 Rated speed | 2200(r/min) |
9 Max. Torque | 902(N.m) /(1400r/min) |
10 Starting type | Electric |
11 Min. specific fuel consumption | 211(g/Kw.h) |
12 Net weight | 617(kg) |
Transmission System | |
1 Model | WG180 technology |
2 Type | 3-elements.single stage |
3 Torque ratio | 2.35 |
4 Cooling type | Pressure oil circulating |
3.Axle and Tire | |
1 Type of main reducer | spiral bevel gear, single stage |
2 Gear ratio of main reducer | 3.583 |
3 Type of final reducer | Single stage chain-drive |
4 Gear of ratio of final reducer | 3.75 |
5 Gear ratio | 13.436 |
6 Tandem drive | Double row roller-chains |
7 Size of tire | 17.5-25-12PR(standard) |
