XCMG Official 3 Ton-5 Ton Tractor Front End Loader Lw300kn Zl50gn China Top Mini Small Wheel Loader with CE Parts for Sale
Xuzhou Construction Machinery Group Co., Ltd.- After-sales Service：Overseas Service Center Available
- Warranty：1year
- Certification：TUV, UL, ISO, RoHS, CE, ISO9001: 2000
- Condition：New
- Rated Load：3-6t
- Transmission：Hydraulic
Base Info
- Model NO.：ZL50GN
- Load and Unload Mode：Front Discharge
- Walking Mode：Wheeled
- Type：Medium-sized Loader
- Transport Package：Comply with Export Packaging Requirements
- Specification：ISO
- Trademark：XCMG
- Origin：Xuzhou, Jiangsu, China
- HS Code：84295100
- Production Capacity：10000,Year
Description
Overview
Product Description
Product ParametersUnit LW300KN Rated operating load kg 3000 Bucket capacity m³ 1.5~2.5 Machine weight kg 10900±200 Dump clearance at maximum lift mm 2770~3260 Reach at maximum lift mm 1010~1210 Wheel base mm 2900 Tread mm 1850 Height of hinge at maximum lift height mm 3830 Working height(fully lifted) mm 4870 Max.breakout force kN 130 Max.horse power kN 95 Hydraulic cycle time-raise s 5.4 Total hydraulic cycle time s 9.3 Min. turning radius over tyres mm 5170 Articulation angle ° 38±1 Gradeability ° 28 Tyre size 17.5-25-12PR Overall machine dimension L×W×H mm 7245×2482×3320 Model WP6G125E201 Emission standards Emission 2 Rated Power/Speed kW/rpm 92/2000 Fuel Tank L 170 Hydraulic Tank L 175 Unit ZL50GN Rated operating load kg 5000 Bucket capacity m³ 2.5~4.5 Machine weight kg 17500±300 Dump clearance at maximum lift mm 3100~3780 Reach at maximum lift mm 1100~1220 Wheel base mm 3300 Tread mm 2250 Max.breakout force kN 175±5 Max.horse power kN 160±5 Hydraulic cycle time-raise s ≤6 Total hydraulic cycle time s ≤10.5 Min. turning radius over tyres mm 5925±50 Articulation angle ° 38 Gradeability ° 30 Tyre size 23.5-25-16PR Overall machine dimension L×W×H mm 8225*3016*3515 Model WD10G220E21 Rated Power kW 162 Travel Speed I-gear(F/R) km/h 13/17 II-gear(F) km/h 41
Company Profile
FAQ
1: What kind terms of payment can be accepted?
A: For terms of payment, L/C, T/T, D/A, D/P, Western Union (can be) could accepted
2: What certificates are available in Machinery?
A: For the certificate, we have CE, ISO, Gost, EPA(USA)CCC,
3: What about the delivery time?
A: 30 days after receiving the deposit.
4: What about the warranty time?
A: 12 months after shipment or 2000 working hours, whichever occuts first.
5. What about the Minimum Order Quantity?
A: The MOQ is 1 pcs.
XCMG wheel loader is the latest cross-generation product developed by XCMG on the basis of the globalized technologic resources.
Focusing on customer value and emphasizing customer experiences, XCMG loader is the first-choice equipment for the production organization in the fields of ports, mines, engineering constructions, and logistics.Product Parameters
Description
Company Profile
FAQ1: What kind terms of payment can be accepted?
A: For terms of payment, L/C, T/T, D/A, D/P, Western Union (can be) could accepted
2: What certificates are available in Machinery?
A: For the certificate, we have CE, ISO, Gost, EPA(USA)CCC,
3: What about the delivery time?
A: 30 days after receiving the deposit.
4: What about the warranty time?
A: 12 months after shipment or 2000 working hours, whichever occuts first.
5. What about the Minimum Order Quantity?
A: The MOQ is 1 pcs.
