• Model NO.：LTS208H
• Travel Speed：35cm,s
• Centrifugal Force：27KN
• Certification：EPA, CS, CE, RoHS, ISO 9001:2000
• Condition：New
• Operating Weight：8000kg
• Wheel Base：2750mm
• Rated Power：75kw
• Engine Model：Chinese Commnus 4bt3.9
• Dimension：5630*2260*3000mm
• Drum Width：1700mm
• Transport Package：Suitable Package for Shipment
• Specification：ISO
• Trademark：LUTONG
• Origin：Luoyang, China
• Production Capacity：50000PCS,Month

Basic Info.

Model NO. LTS208H Travel Speed 35cm/s Centrifugal Force 27KN Certification EPA, CS, CE, RoHS, ISO 9001:2000 Condition New Operating Weight 8000kg Wheel Base 2750mm Rated Power 75kw Engine Model Chinese Commnus 4bt3.9 Dimension 5630*2260*3000mm Drum Width 1700mm Transport Package Suitable Package for Shipment Specification ISO Trademark LUTONG Origin Luoyang, China Production Capacity 50000PCS/Month

Product Description

Hydraulic single driver vibratory roller is manufactured according to the international advanced technology and by use of imported components from abroad. The machine is super heavy-duty vibratory roller, possesses a great working mass and strong centrifugal force. It is the best compaction equipment of high quality and hegh effect in the large-scale mechanized construction. This machine is suitable for non-cohesive materials, such as graves, macadam, macadam-aggregate mixtures and sandy soil etc. Also it can effect good compaction in cohesive material, There-fore the machine an ideal equipment for expressway. Mining road, embankment, sea port and industrial sites.
Main Features
Power System: CUMMINS B-series extra-pressure diesel engine, huge power man coeffciency, complicable for the operating condition above 4000 meters altitude.
Full hydraulic and rear wheel drive, changable frequency changable amplitude, articulated steering, the advanced two speedless changes, Break-off oil system safe and reliable for the braking.
Streamline outline, circular windshield glass and curvy hood form a unique style.
Equipped with padfoot or removal padfoot as optionHydarulic pump and vibrating motor are of thr 90 series made by American manufacturer SAUER or German munufacturer REXROTH

MODEL		LTS208H
Operating mass	Kg	8000
Static linear load	N/cm	235
Vibrating amplitude	Mm	0.4
Vibrating frequency	Hz	43
Centrifugal force	KN	70
Travel speed	Km/h	0-15
Grade ability	%	35
Turning radius	mm	5000
Overall dimension	mm	5630x2260x3000
Ground clearance	mm	320
Vibration drum width	mm	1700
Drum rim thickness	mm	24
Wheelbase	mm	2750
Diesel model		Cummins  4BT3.9
Diesel power	Kw	75
Traving  Systerm	Brand	SAUER DANFOSS (USA) or REXROTH (GERMANY)
Vibration Systerm	Brand	JOINT VENTURE
