Xz1000 Horizontal Directional Drill
Evangel Industrial (Shanghai) Co., Ltd.- Type：Drill
- Pressure Pile Driver Type：Mechanical Pile Driver
- Pile Hammer Type：Hydraulic Hammer
- Power Source：Diesel
- Motor Power：90kw
- Noise：Without Noise
Base Info
- Model NO.：Horizontal Directional Drill
- Certification：CS, CE
- Condition：New
- Layout：Horizontal
- Automation：Semi-Automatic
- Drilling Speed：:>100 M,H
- Drill Direction：Vertical
- Rated Power：392kw
- Dimension(Lxwxh)：14500× 3150× 3390mm
- Precision：Normal Precision
- Control：Artificial
- Depth of Drilling：>300 M
- Engine：Cummins
- Transport Package：Nude
- Specification：CE, RoHS, SGS, GMP
- Origin：Jaingsu China
- HS Code：84295100
- Production Capacity：50, 000 PCS,Year.
Description
Basic Info.
Model NO. Horizontal Directional Drill Certification CS, CE Condition New Layout Horizontal Automation Semi-Automatic Drilling Speed :>100 M/H Drill Direction Vertical Rated Power 392kw Dimension(Lxwxh) 14500× 3150× 3390mm Precision Normal Precision Control Artificial Depth of Drilling >300 M Engine Cummins Transport Package Nude Specification CE, RoHS, SGS, GMP Origin Jaingsu China HS Code 84295100 Production Capacity 50, 000 PCS/Year.Product Description
Features:
Rigid track, truck-carrying type, travel controlled by wire, quick and convenient site transfer.
The Cummins turbocharged engine has large power reserve, ensuring the thrusting power and the need in emergent conditions.
Advanced load sensing control and electro-hydraulic proportional control technology, imported hydraulic parts, and independent radiating system, ensure energy saving, reliable and efficient work.
Driving head slewing and gear rack push-pull system, 2 gear stepless speed adjustment, and high work efficiency.
Equipped with 3.2 t auxiliary hoist machine, the installation and removal of drill pipe is easy and efficient.
2 seats, all day cab, color monitoring instrument, comfortable to operate.
Interlock when get on or off the machine, automatic protection under high pressure, engine and hydraulic parameter monitoring and alarming, effectively protect the machine.
Manual control system is available for special conditions, and this ensures safety during operation.
| Model | XZ1000 | |
|---|---|---|
| Engine | CUMMINS | |
| Rated power | kW | 392 |
| Max.pullback/thrusting | kN | 1000/1000 |
| Spindle torque (max) | N.m | 55000 |
| Spindle speed | r/min | 0-80 |
| Backreaming diameter | mm | Ø1200 |
| Tubing length(single) | m | 9.6 |
| Tubing diameter | mm | Ø127 |
| Entry angle | ° | 10-18 |
| Mud flow rate (max) | L/min | 1200 |
| Mud pressure (max) | bar | 200 |
| Overall weight | kg | 32000 |
| Dimension(LxWxH) | mm | 14500×3150×3390 |
