• Model NO.：ZL50CN
• Type：Medium-sized Loader
• Product Name：Construction Equipment Payloader Mini
• Export：Front End Loader Export to Over 100 Countries
• Operating Weight：17.5 Tons
• Transport Package：Stand Export Package
• Trademark：Liugong
• Origin：China
• Production Capacity：1000units,Month

Basic Info.

Model NO. ZL50CN Type Medium-sized Loader Product Name Construction Equipment Payloader Mini Export Front End Loader Export to Over 100 Countries Operating Weight 17.5 Tons Transport Package Stand Export Package Trademark Liugong Origin China Production Capacity 1000units/Month

Product Description

Liugong Wheel Loader Pay Loader Front End Loader ZL50CN


• Product-Features

• Optimizing the shape of the bucket makes it easy to pick up material, achieving higher fill factors and less spillage.
• A/C with big cooling capacity, adding air from back and bottom of machine for all-round effect.
• Optimized preheating system and hyperboloid efficient fan, adaptable from -30 ºC ~ 45 ºC ambient temperature.
• Optional multiple attachments, including: multiple buckets, pallet fork, handing arm, grapple and snow blade greatly expands the applications of the wheel loader.

Specifications ZL50CN-ZL50CN

Operating weight 16500-17300 kg

Standard bucket 3 m³

Gross power 162 kW (220 hp) @ 2200 rpm

Net power 148 kW (201 hp) @ 2200 rpm

Rated load 5000 kg

Total cycle time 11.5 s

Tipping load-full turn 11000 kg

Bucket breakout force 167 kN

Dump clearance, full height discharge 2970 mm

Dump reach, full height discharge 1200 mm

Model 6LT9.3

Emissions: EPA Tier 2 / EU Stage II

Cooling system: Charge air cooling

Length with bucket down: 7598 mm

Width over tires: 2976 mm

Cab height: 3480 mm

Turning radius, outside of tire: 6647 mm

Bucket capacity: 1.8-5.6 m³

General Purpose: 3 m³

Light material: 3.0, 4.5, 5.0, 5.6 m³

Heavy-rock: 2.7 m³



816C

Operating weight:5400-5800 kg

Rated power:55 kW

Rated operating load:1000 kg



816G

Operating weight:5500-5900 kg

Rated power:50.2 kW

Rated operating load:1000 kg

825C

Operating weight:8500-9500 kg

Rated power:75 kW

Rated operating load:2500 kg

835H

Operating weight:10300-10900 kg

Rated power:92 / 98 / 119 kW

Rated operating load:3000 kg

836

Operating weight:10300-11000 kg

Rated power:92 kW

Rated operating load:3000 kg

840H

Operating weight:12300-12500 kg

Rated power:112kW

Rated operating load:4000 kg

842H

Operating weight:12700-13100 kg

Rated power:129 kW

Rated operating load:4000 kg

848H

Operating weight:14200-15500 kg

Rated power:135 / 136 kW

Rated operating load:4500 kg

855H

Weight:16700-17200 kg

Power:162 kW

Load:5000 kg

ZL50CN

Operating weight:16500-17300 kg

Rated power:162 kW

Rated operating load:5000 kg

856H

Operating weight:17000-18000 kg

Rated power:162 / 168 / 172 / 183 kW

Rated operating load:5000 kg

862H

Operating weight:19500-21000 kg

Rated power:179 / 180 kW

Rated operating load:6000 kg

877H

Operating weight:24000-25000 kg

Rated power:220 / 247 kW

Rated operating load:7000 kg

886H

Operating weight:25300-26500 kg

Rated power:235 / 272 kW

Rated operating load:8000 kg

890H

Operating weight:30600-31000 kg

Rated power:276 / 287 kW

Rated operating load:9000 kg

8128H

Rated operating load:52000 kg

Rated power:419 kW

Rated operating load:12000 kg
