Concrete Mixer Truck Gear Box
Hangzhou Advance Gearbox Group Co., Ltd.- Type：Concrete Mixing Truck
- Machining Process：Hydraulic
- Condition：New
- Color：as Shown in Figure
- Transport Package：Wooden Cases or According to Your Requirements
- Specification：ISO9001
Base Info
- Model NO.：JJ-90,100,120
- Trademark：ADVANCE
- Origin：China
- Production Capacity：1000 Sets,Month
Description
| basic parameter | |||
| Model | JJ-90 | JJ-100 | JJ-120 |
|
Supporting mixing tank capacity |
8~9m³ | 10m³ | 12m³ |
|
Maximum output torque |
56000Nm | 62000Nm | 74000Nm |
| reduction ratio | 134: 1 | 136: 1 | 145: 1 |
|
Installation Max Angle |
15/12 | 11 | 10 |
| Weight | 333KGS | 342KGS | 349KGS |
|
Alternative similar products |
|||
| Made In China | JJ-90 | JJ-100 | JJ-120 |
| ZF | PA300/PLM9 | P5300 | P7300 |
| PMP | PMB6.5CP/SP | PMB7.2CP/SP | PMB8 |
| BONFIGLIOLI | 575 | 577 | 580 |
