Electric/Gasoline Professional Frame Vibratory Truss Screeds
Jining Furuide Machinery Manufacturing Co., Ltd.- Type：Concrete Truss Screed
- Machining Process：Concrete Leveling Machine
- Certification：ISO9001: 2000, CE
- Condition：New
- Power：13HP
- Engine：Honda Petrol or Electric
Base Info
- Model NO.：FZP-130
- Working Depth：260mm
- Working Width：8-50m
- Transport Package：Wooden Case
- Specification：IS09001
- Trademark：FURD
- Origin：China
- HS Code：8479102100
- Production Capacity：50, 000 PCS,Year
Description
| Model | FZP-55 | FZP-90 | FZP-130 | ||
| Engine Model | HONDA GX160 | HONDA GX270 | HONDA GX390 | ||
| Power | 5.5HP/3.0kw | 9HP/4.0kw | 13.0HP/5.0kw | ||
| Type | Gasoline engine, air-cooled 4-stroke, OHV, single cylinder | ||||
| Working width | 4-8m | 8-12m | >12m | ||
| Working depth | 260mm | ||||
| Vibration frequency | 70Hz | ||||
| Induced vibration force | 11kN/(≤)2000mm | ||||
| Fuel tank capacity | 3.6L | 6L | 6.5L | ||
| The amount of lubricating oil | 0.6L | 1.1L | |||
| The amount of fuel consumption | 313g/kWh | ||||
| Dimensions | |||||
| Standard knot | 1000/2000mm | ||||
| 2m linker | 400mm×2000mm | 68kg | |||
| 1m single linker | 400mm×1000mm | 35kg | |||
| 0.5m single linker | 400mm×250mmX2 | 15kg | |||
