• Parts Name 4：Pipe Joint
• Parts Name 5：Acoumalator(to Be Full)
• Parts Name 6：Roker Arm
• Parts Name 7：Gasket
• Parts Name 8：Idler Gear
• Parts Name 9：Gear
• Parts Name 10：Main Water Pump
• Transport Package：Paper Box or Wooden Box
• Specification：unit
• Trademark：Kalmar
• Origin：China
• HS Code：8431499900
• Production Capacity：10000 Pieces ,Year

Basic Info.

Parts Name 4 Pipe Joint Parts Name 5 Acoumalator(to Be Full) Parts Name 6 Roker Arm Parts Name 7 Gasket Parts Name 8 Idler Gear Parts Name 9 Gear Parts Name 10 Main Water Pump Transport Package Paper Box or Wooden Box Specification unit Trademark Kalmar Origin China HS Code 8431499900 Production Capacity 10000 Pieces /Year

Product Description

Throttle and check throttle valves
Model Z2FS
Superimposed double one way throttle valve·
Sizes 6 to 22
Mounting surface according to DIN 24340 type A and ISO 4401
It is used to limit the main flow quantity or control oil quantity of one or two working ports
For inlet throttling or outlet throttling control·
4Optional adjustment methods:
Hexagon socket screw with shield
Dial knob with lock
Dial knob
Spindle with scale and hexagon



Model Z2FSK
Superimposed double one way throttle valve 210bar series
Sizes 6 and 10
Mounting surface according to DIN 24340 type A and ISO 4401
It is used to limit the main flow quantity or control oil quantity of one or two working ports
For inlet throttling or outlet throttling control


Models MG and MK
Throttle valve and one way throttle valve
Sizes 6 to 102
Pipeline installation
Performance is affected by pressure and viscosity
Mg type: bidirectional throttling
MK type: unidirectional throttling, free flow in the opposite direction (opening pressure is 0.5bar)
Optional surface coating
For special flow (e.g. emulsion, water), please contact our company



Model F
Precision throttle valve
Two way throttling
Base plate installation
Threaded connection
Valve block connection
Knob with lock
Flow control valve



 Z2FRM
Stacked 2-way flow control valve
Specification 6
Mounting surface mounting DIN 24340 type A and ISO 4401
There is flow control at a, B, a and B or T (P) ports



 Models 2FRM, 2frh and 2frw
2Flow control valve
Sizes 6 to 16
Base plate installation
Specification 6: mounting surface according to DIN 24340 type A and ISO 4401
Specifications 10 and 16: mounting surface according to DIN 24340 type G and ISO 6263
Manual trigger (2FRM type)
Hydraulic trigger (2frh type)
Electrohydraulic trigger (2frw type)
Two way flow control with stacked plate rectifier (see below, z4s type)
Stroke limiter for rack piston with adjustable limit at both ends (2frh and 2frw types)
True value potentiometer for orifice position monitoring at sight, optional (2frh and 2frw models)
Pressure compensator external closed, optional (size 6)
Check valve, optional (size 6)
Travel stop for pressure compensator to reduce starting shock (sizes 10 and 16)


2FRM.K
2Flow control valve
Sizes 6 and 10
As cartridge valve ("K")
There is an integrated check valve
Low starting shock
Rectifier stack



Model Z4S
Rectifier stack board (Graetz circuit) for integration of flow control valves
Sizes 6 to 16·
Ensure that the flow through the built-in flow control valve is rectified·
It can be used to supply and return fluids
