• Model NO.：YZ12H
• Compaction Depth：30cm
• Engine Type：Diesel Engine
• Travel Speed：30cm,s
• Centrifugal Force：13KN
• Certification：CS, ISO 9001:2000, ISO 9001:2008
• Condition：New
• Operating Weight：12000kg
• Static Weight at Drum：6500kg
• Theoretical Gradeability：20%
• Engine Model：6bt5.9-C150
• Max. Power：132kw
• Drum Diameter：1530mm
• Specification：6000*2300*3055mm
• HS Code：8501109190
• Production Capacity：200

Driving System

1

Model

Static Hydraulic stepless driving

2

Type

Drive pump +drive motor + reducer

3

Model of drive pump

A4VG90HWDL1/32R

4

Model of drive motor

AA2FM80/61W

5

System pressure

40MPa

6

Type of reducer

Spur gear parallel shaft constant-mesh

7

Gear ratio of reducer

2.94
