Yn966g Wheel Loader Cat Engine 3.5cbm

Shandong Yineng Heavy Industry Co., Ltd.
  • Certification：CE, ISO9001: 2000, ISO9001:2008
  • Condition：New
  • Rated Load：6000kg
  • Transmission：Hydraulic - Mechanical Transmission
  • Walking Mode：Wheeled
  • Type：Large Loader

Base Info

  • Model NO.：Yn966G Wheel Loader Cat Engine 3.5cbm
  • Rated Capacity：3.5m3
  • Max. Tractive Force：170kn
  • Max. Breakout Force：190kn at Least
  • Max. Dumping Height：3100mm
  • Tire：26.5-25
  • Usage：Universal Type
  • Scraper Type：Pull Scraper
  • Load and Unload Method：Front Discharge
  • Color：Yellow
  • Engine Power：175kw
  • Transport Package：Naked in 40′hq Container or RO-RO Vessel
  • Specification：CE; ISO; GOST
  • Trademark：YINENG
  • Origin：Taian City, Shandong Province, China
  • HS Code：84295400
  • Production Capacity：10000

Description






Performance1Rated load6000kg2Overall weight19200kg3Rated capacity3.5m34Max. Tractive force170KN5Max. Breakout force≥190KN6Max. Grade ability30°7Max. Dumping height3100mm8Max. Dumping reach1250mm9Overall dimension L x W x H8160x3070x3400mm10Min. Turning radius6630mm

Engine11ModelShangchai CAT SC11CB240.1G2B112TypeInline/Turbocharged/water colling13No. Of cylinder-bore/stoke6-121x152mm14Rated power175kw-2200r/min15Max. torque950N.m16Min. Fuel-consume ratio≤215g/kw.h
Transmission17ModelWG200 Gearbox18Gear shift4 forward, 3 reverse.
Electronic control gear shift19Max. speed38km/h

Drive axle20Main reducing spiralBevel gear grade 1 reduction21Decelerating modePlanetary reduction, grade 1.22Wheel base3200mm23Wheel tread2250mm24Min. ground clearance510mm
Hydraulic system25System working pressure18MPa26Boom lifting time6.0+0.2s27Total time12+0.5s28Fuel tank capacity300L29Leveling automaticallyYes
Break system30Service brakeAir over hydraulic disc brake on 4 wheels31Parking brakeexpand hoof type
Tyre32Type26.5-2533Front tyre pressure0.4Mpa34Rear tyre pressure0.35MpaRemark: Joystick control, electronic control, ZF TECH WG200 gearbox, heavy chassis for standard

2. Quality certificate:
(1) CE Approved.
(2) Obtained the certificate of ISO9001:2008.
(3) Manufacturing license number: TS2510025-2009.

3. Quotation:
YN966 Wheel Loader (with 3.5 CBM, 6.0 ton capacity, Shangchai CAT SC11CB240.1G2B1 engine, Electronic control WG200 gearbox, Joystick control, Heavy chassis, luxury cabin.)


4. Others:
(1) Packing: 1 unit naked within 1 x 40HQ container
(2) Delivery time: 40 days
(3) Accidental benefits: Customers can purchase wearing parts according to the parts list we offered.
(4) Guarantee Period: One year
(5) Offer Validity: 30 days
