- HS Code：8479109000
- Production Capacity：50 PCS,Month
| TRUEMAX SC200/200 series hoists comparison |
| Model | General low speed
domestic motor & reducer | VFD Low speed
domestic motor & reducerr | VFD Low speed
imported motor & reducer |
| Item | Unit | Parameter, index and instruction |
| Rated load capacity | kg | 2000 | 2000 | 2000 |
| Max installation height | m | 150 | 450 | 450 |
| Lifting speed | m/min | 34 | 0~40 | 0~40 |
| Motor working system | kw | 3×11 | 3×11 | 2×11 |
| Motor working system | | S3-25% | S3-25% | S1-100% |
| Speed radio of reducer | | 1:16 | 1:16 | 1:23 |
| Inverter power | kw | - | 45 | 37 |
| Up going acceleration time | s | - | 5 | 5 |
| Down going acceleration time | s | - | 2 | 2 |
| Motor rated current | A | 70.5 | 70.5 | 72.4 |
| Startup instantaneous current | A | 350~490 | <70 | <58 |
| Full load up going current | A | <76 | <70 | <58 |
| Full load down going current | A | >48 | <1.5 | <1.5 |
| Ratio of energy saving | | - | >30.5% | >32% |
| Service life for wearable parts(estimated value) |
| Small pinion | Month | 6 | 12 | 12 |
| Small roller wheel | Month | 6 | 12 | 12 |
| Brake piece | Month | 6 | 18 | 18 |
| Rack | Year | 2 | 4 | 4 |
| Power consumption per month(estimated value) |
| Ammeter(8h×30day) | kw*h | 11712 | 8160 | 7960 |
| Percentage of power consumption | | 100% | 69.70% | 68% |
