• Transport Package：Export Packing
• Specification：As per excavator type
• Trademark：UT
• Origin：Shandong China
• Production Capacity：1000piece,Month

Basic Info.

Transport Package Export Packing Specification As per excavator type Trademark UT Origin Shandong China Production Capacity 1000piece/Month

Product Description

Side Type Hydraulic Breaker Features :

1. It applies the best design scheme and is formed by using the fewest parts; it is less in fault and easy to maintain, and famous for light and powerful operation and wide use; it is mainly used for quarrying, mine, asphalt pavement removal, greening construction, and breaking of general concrete or rock
2. UT triangular type hydraulic breaking hammer is more capable of meeting the demand of the vast user. Powerful attacking force, ultra-strong breaking performance, and excellent operation performance are perfectly combined into one.
3. The breaking hammer has small working flow, low working pressure, high-performance energy accumulator, and outstanding durability, so it is the first-choice brand of primary breaking.

Item/Model /	Unit	UTHBS450	UTHBS530	UTHBS680	UTHBS750	UTHBS850	UTHBS1000	UTHBS1350	UTHBS1400	UTHBS1550	UTHBS1650	UTHBS1750	UTHBS1800	UTHBS1900
Operating Weight	Kg	100	130	250	380	510	760	1450	1740	2500	2900	3750	3900	3950
Required oil flow	L/Min	20-40	25-45	36-60	50-90	45-85	80-120	130-170	150-190	150-230	200-260	210-280	280-350	280-350
Working pressure	Bar	90-120	90-120	110-140	120-170	127-147	150-170	160-185	165-195	170-200	180-200	180-200	190-210	190-210
Impact rate	Bpm	700-1200	500-1100	500-900	400-800	400-800	400-650	400-650	400-800	400-800	250-400	250-350	230-320	230-320
Chisel Dia.	mm	45	53	68	75	85	100	135	140	155	165	175	180	190
Hose Dia.	Inch	1/2	1/2	1/2	1/2	1/2	3/4	1	1	1	1.1/4	1.1/4	1.1/4	1.1/4
Suit Excavator	Ton	1.2-3	2.5-3	3-7	6-9	7-14	10-15	18-25	20-30	27-36	30-45	40-50	45-55	50-60
Valve Assy's Position	/	Internal	Internal	Internal	Internal	Internal	Internal	Internal	Internal	Internal	Internal	Internal	Internal	Internal

The specifications may vary with different excavators and are subject to change without prior notice for products improvement.
