25 M3/H Wheeled Concrete Batching Plant with Capacity (HLS25)
Phoenix Heavy Industrial (China) Co., Ltd.- Type：Concrete Mixing Plant
- Machining Process：for Concrete Mixer Trucks
- Certification：ISO9001: 2000, CE
- Condition：New
- Capacity：25 M3,H
- Advantage：Mobile Type
Base Info
- Model NO.：HLS25
- Transport Package：Nude Packing
- Specification：ISO9001
- Trademark：PHOENIX
- Origin：China Mainland
- HS Code：84743100
- Production Capacity：1000sets,Year
Description
| NO. | Name | Project | QTY | ||
| 1 | Mixer System JS500 | 1 | |||
| Reducer | XWD185-8-1/17 | 1 | |||
| Cylinder | QGB80X200-S | 1 | |||
| Motor | Y200L-4 | 1 | |||
| Mixing Plant | 1 | ||||
| Mixing Tank | 1 | ||||
| Gearing | 1 | ||||
| Mixer Cover | 1 | ||||
| 2 | Aggregate Measurement | 1 | |||
| Electric Drum | 4Kw, 1M/S b=650mm | 1 | |||
| Flat belt | B=650, L=8500mm | 1 | |||
| Groove Stick Group , Pinto Roll Group | 14 | ||||
| Cylinder | QGB80X325-S | 2 | |||
| Direction Change Drum | 1 | ||||
| Chassis | 1 | ||||
| 3 | Aggregate Conveyor | 1 | |||
| Trough Belt | B=650,L=1500 | 1 | |||
| Electric Drum | 4Kw, 1M/S B=650mm | 1 | |||
| Pinto Roll Group | 14 | ||||
| Belt Tension Device | 1 | ||||
| Connect , Material Gate | 1 | ||||
| 4 | Aggregate As sembly | 1 | |||
| Aggregate Measuring bin | 1 | ||||
| Aggregate Storage bin | 8 m3 | 2 | |||
| Storage bin extension board | 5 | ||||
| Discharge Gate | 4 | ||||
| Load Cell | CBLJ-1000 | 4 | |||
| Chassis | 1 | ||||
| 5 | Cement Measurement | 1 | |||
| Cement Measurement Bucket | 1 | ||||
| Discharging Cylinder | QGB80-125-S | 1 | |||
| Discharging Butterfly Valve | D=250 | 1 | |||
| Venthole Pipeline | 1 | ||||
| Load Cell | CBLG-300 | 3 | |||
| 6 | Water Measurement | 1 | |||
| Water Measurement Bucket | 1 | ||||
| Watering Pipe | 1 | ||||
| Discharging Water Butterfly valve | D-125 | 1 | |||
| Load Cell | CBLG-200 | 3 | |||
| Pump | IS65-50-125 | 1 | |||
| 7 | Admixture Measurement System | 1 | |||
| Admixture Measurement Cylinder | 1 | ||||
| Admixture Pipe | 1 | ||||
| Discharging Water Butterfly Valve | D=50 | 1 | |||
| Load Cell | CBLG-50 | 1 | |||
| 8 | Electrical Control System | 1 | |||
| Cement Batching Computer | HZDP=150 | 1 | |||
| Control Platform | 1 | ||||
| Wires and Cables | 1 | ||||
| 9 | Pneumatic System |
PX200300 Air compress PX200300 |
1 | ||
| Pneumatic Case | 1 | ||||
| Pipeline Joint and Fixed Block | 1 | ||||
| Filters KGL-40 | 1 | ||||
| Pneumatic Pipe | 1 | ||||
| 10 | Chassis | 1 | |||
| Leading Steering | 1 | ||||
| Front Axle & Shock Absorption | 1 | ||||
| Back & Shock Absorption | 1 | ||||
| Braking and Pneumatic | 1 | ||||
| Signal and Circuit | 1 | ||||
| Towbar | 1 | ||||
| Outrigger | 8 | ||||
| 11 | Ladder and Platform Guardrail | 1 | |||
| 12 | Cement Silo | 50T | 1 | ||
| Dust Removal | 1 | ||||
| Level Gage | 1 | ||||
| Broken Arch System | 3 | ||||
| Tank and Cone | 1 | ||||
| Feeder Pipe and Orifice | 1 | ||||
| Bracket and La dderstand | 1 | ||||
| 13 | Screw Conveyor | φ219 | 1 | ||
| Front-bracket Assembly | 1 | ||||
| Middle-bracket Assembly | 1 | ||||
| Reducer | 1 | ||||
| Motor | Y160L-4,11Kw | 1 | |||
| Continuous Vane and Inner Shaft, etc | 1 | ||||
| Outside Pipe and lubricant passage way | 1 | ||||
