Yellow 5 Ton Wheel Loader Big Bucket Construction Machinery CE ISO SGS OEM
Qingzhou Titan heavy Machinery Co., Ltd.Base Info
- Model NO.：AL50
- After-sales Service：maintain
- Warranty：One year
- Certification：TUV, UL, ISO, RoHS, CE
- Condition：New
- Rated Load：3-6t
- Transmission：Hydraulic - Mechanical
- Load and Unload Mode：Front Discharge
- Walking Mode：Wheeled
- Type：Medium-sized Loader
- Overall weight：16500kg
- Rated bucket capacity：3m3
- Maximum traction force：≥168KN
- Maximum breakout force：≥170KN
- Maximum grade ability：30°
- Maximum dump height：3142mm
- Maximum dump reach：1250mm
- Overall dimension (L×W×H)：8085×2963×3463mm
- Minimum turning radius：6732mm
- Model：Weichai Steyr WD10G220E21
- No. of cylinder-bore/stroke：6-126×130mm
- Rated power：162kw--2400r,min
- Maximum torque：890N.m
- Min fuel-consume ratio：≤215g,kw.h
- Rated load.：5000kg
- Trademark：Abbasist
- Transport Package：Nude in Container
- Specification：6470,2120,2960mm
- Origin：Shandong China
- HS Code：84295100
