• Model NO.：W2330LC-8
• Size：Large-Scale
• Certification：CE, ISO9001: 2000
• Condition：New
• Excavator：Excavator 330
• Track Width：600mm
• Engine Power：250HP
• Hydraulic Pump：Kawasaki
• Max. Digging Height：10200mm
• Max. Digging Depth：7300mm
• Max. Dumping Height：7150mm
• Min. Turning Radious：3405mm
• Bucket Width：1282mm
• Travel Speeds：4.6km,H
• Transport Package：by Roro or Bulk Vessel
• Specification：ISO CE Gost-R
• Trademark：WORLD
• Origin：CHINA
• HS Code：84295112
• Production Capacity：3000PCS,YEAR

ItemsModel: W2330LC-8Engine SystemBrand & OriginIsuzu (Japan)ModelAA-6HK1XQPRated Power (kw/rpm)183.9/2200Max. Torque (N.m)872.8/1700rpmIdle Speed (rpm)1050Engine Displacement (L)7.79Cylinder No.-Bore x Stroke (mm)6-115x125Engine Oil Capacity (L)28-36Fuel Tank Capacity (L)630Fuel Consumption Rate (g/kw.h)236.6Hydraulic SystemMain PumpBrand & OriginKawasaki(Japan)Rated Pressure (MPa)31.4/34.3Nominal Displacement (cm3/rev)132.5x2Multiple Unit ValveBrand & Originkawasaki(Japan)Rated Pressure (MPa)31.4/34.3Hydraulic MotorTravel Motor Brand & OriginKYB (Japan)Traveling Speed (H/L km/h)4.7/2.9Swing Motor Brand & OriginKawasaki(Japan)Swing Speed (r/min)10.5Hydraulic CylinderBoom Cylinder (mm)140x100Arm Cylinder (mm)160x110Bucket Cylinder (mm)140x100Hydraulic Oil Tank Capacity (L)27-31Working SpecificationsWeight (kg)33000Bucket Capacity (m3)1.38Bucket Width (mm)1282Bucket Digging Force (kN)171Arm Digging Force (kN)150Ground Pressure (KPa)60Grade ability70%Max. Digging Depth (mm)7300Max. Digging Height (mm)10200Max. Digging Radius (mm)11100Max. Discharging Height (mm)7150Min. Ground Clearance (mm)503Min. Swing Radius (mm)3450Overall Dimensions (mm)L:10810xW:3190xH:3200
