• Model NO.：63X-7RZ
• Productivity：180cbm,H
• Feeding Height：63m
• Vibrating Amplitude：2.0mm
• Certification：ISO9001: 2000, CE
• Condition：New
• Color：Green
• Max. Vertical Conveying Distance：63m
• Max. Horizontal Conveying Distance：57m
• Transport Package：Nude Package
• Specification：13915*2500*4000mm
• Trademark：ZOOMLION
• Origin：China
• Production Capacity：15sets,Mon







Pump Unit

Maximum pressure on concrete                  m3/h      180Maximum pressure on concretebar110Conc. cylinders (diam. x stroke)mm260×2100Concrete hopper capacityL600Hydraulic circuit Closed









Boom Section

Maximum vertical reachm62.1Maximum horizontal distancem56.9Minimum unfolding heightm15.8Section numbers 7Rotating angle ±270°End hose lenghtm3
