China Original Factory Wheel Type Asphalt Paver RP603L with Moba Leveling Instrument

Oriemac Machinery & Equipment (Shanghai) Co., Ltd.
  • Type:Paver
  • Object:Asphalt Concrete Pavement
  • Moving Type:Mobile
  • Mixing Method:Continuous Drum
  • Automatic Grade:Automatic
  • Product Capacity:40~400t,h

Base Info

  • Model NO.:RP603L
  • Certification:ISO9001: 2000, CE
  • Condition:New
  • Basic Paving Width:2.5m
  • Max. Paving Width:6m
  • Max. Paving Thickness:260mm
  • Engine:Sc4h140g3
  • Power:103,2200kw,Rpm
  • Dimension:6660×2600×4000mm
  • Maximum Paving Speed:17m,Min
  • Maximum Travel Speed:15km,H
  • Hopper Capacity:13t
  • Gradeability:20%
  • Heating of Screed:Electric,Gas Heating
  • Travel Type:Tire
  • Transport Package:Main Machine Nude, Attached Parts Into Export Case
  • Specification:16500kg
  • Origin:Jiangsu China
  • HS Code:84791021
  • Production Capacity:100 Unit Per Month

Description

Basic Info.

Model NO. RP603L Certification ISO9001: 2000, CE Condition New Basic Paving Width 2.5m Max. Paving Width 6m Max. Paving Thickness 260mm Engine Sc4h140g3 Power 103/2200kw/Rpm Dimension 6660×2600×4000mm Maximum Paving Speed 17m/Min Maximum Travel Speed 15km/H Hopper Capacity 13t Gradeability 20% Heating of Screed Electric/Gas Heating Travel Type Tire Transport Package Main Machine Nude, Attached Parts Into Export Case Specification 16500kg Origin Jiangsu China HS Code 84791021 Production Capacity 100 Unit Per Month

Product Description

China Original Factory Wheel Type Asphalt Paver RP603L with MOBA Leveling Instrument
Product description

RP603L paver is the first full-hydraulic medium 3 series wheeled paver . This machine adopts full-hydraulic drive and electro-hydraulically automatic control, featuring advanced technologies and reliable performance. It's extensively applied for the large scope paving operations, including sidewalks, non-motorized vehicle lanes, urban roads, and small roads. With the paving width continuously adjustable from 2.5m to 6.0m, it's especially suitable for the maintenances of classified highways.

Parameter
ItemUnitRP603L
Basic paving widthm2.5
Max. paving widthm6
Max. paving thicknessmm260
Paving speedm/min0~17
Travel speedkm/h0~15
Theoretical productivityt/h400
Hopper capacityt13
Gradeability%20
Diesel engine model SC4H140G3
Diesel engine powerkw103
Diesel engine speedr/min2200
Overall weightt16.5
Dimensionmm6660×2600×4000
Vibration frequencyHz/
Screed heating mode Electrical heating
Material level control mode Automatic Control by Ultrasonic Sensor
Automatic Leveling Control Simulation control
