• Model NO.：SEM816LGP
• Condition：New
• Color：Yellow
• Operating Weight：19720kg
• Engine：Weichai
• Blade Capacity：6.4cbm
• Blade Width：3720mm
• Transport Package：Nude Package
• Specification：20ton
• Trademark：SEM
• Origin：China
• Production Capacity：300 Units Per Month

ModelOperating Weigh t17,230 kgGround Pressure68 kPaGround Clearance410 mmMax.Slope30°EngineModelWeichai WD10G178E25Rated Power131 kW / 175 hpWorking ToolBlade TypeSUBlade Capacity4.3 m³ ( S 3.4 m³ )Blade Width3 , 140 mm ( S 3,490mm )Blade height1,240mm ( S 1,165mm )Max. Blade Digging Depth430 mmMax. Blade Lift Ground Clearance1,041 mmMax.Output Rimpull280 kNMaximum Digging Depth Of Ripper584 mmMaximum Clearance Under Tip615 mmPowertrainTypeElectronic control, Dual-path, Hydrostatic DriveTravel Speed- F/R0 - 10 km/hr (Infi nitely Variable Speed Control)Steering & BrakeHydrostatic Steering, Wet, Multiple-Disc BrakesMinimum Streeing Radius3610 mm (Counter-rotated avaliable)UndercarrigeTrack Shoe Width510 mmTrack Shoe Quantity37 pieceLength Of Track On Ground2,430 mmTrack Gauge1,880 mmTrack Roller Quantity6/SideCarrier Roller Quantity2/SideHydraulic SystemTypePilot ControlImplement Hydraulic System Pressure19 Mpa
