• Model NO.：Zd320-3
• Condition：New
• Color：Yellow
• Working Mass：35044
• Blade Capacity：11.6TM3
• Engine Model：Nta855-C360
• Rated Power/Slewing Speed：257
• Max. Torque：1509,1400
• Max. Lift Height of Dozer：1560mm
• Max. Drop Depth：560tmm
• Max. Lift Height of Ripper：Single-Shank 960 Multi-Shank 890
• Max. Ripping Depth of Ripper：Single-Shank 1235 Multi-Shank835
• Max. Tilt：1000mm
• HS Code：8429521200
• Production Capacity：1000,PCS

 ItemUnitZD320-3ZD320M-3Key    Technical ParameterBlade type-Small Semi-U BladeSmall Semi-U BladeWorking masskg3504435100Blade capacitym311.611.6Engine model-NTA855-C360NTA855-C360Rated power/Slewing speedkW/rpm257257Max. torqueN.m/rpm1509/14001412/1400Min. fuel consumptiong/kW.h242242Max. Drawbar pullKn302355Ground pressurekPa106106Gradeability°°3030Traveling speed of forwardkm/h3.6/6.6/11.53.7/6.8/11.8Traveling speed of Reversekm/h4.4/7.8/13.54.5/8.2/13.7Basic    Technical ParameterHeight of cabmm36003570Height of ROPSmm36873673Ground contact lengthmm31503150Height of blademm17051553Track center distancemm21402140Height of grousermm8080Track shoe widthmm560560Operating    RangeMax. lift height of dozermm15601560Max. drop depthmm560560Max. lift height of rippermmsingle-shank 960
   multi-shank 890890Max. ripping depth of rippermmsingle-shank 1235
   multi-shank835835Max. tiltmm10001000
