Stg230c-8 230HP Small Motor Grader with Front Blade
Oriemac Machinery & Equipment (Shanghai) Co., Ltd.- Warranty：1 Year
- Certification：ISO, CE
- Condition：New
- Application：Railway, Mine, Farmland, Highway
- Transmission：Hydraulic
- Walking Mode：Wheeled
Base Info
- Model NO.：STG230C-8
- Type：Large Grader
- Engine Model：D07s3-231e0
- Forward Speed：6,10,13,21,27,42km,H
- Height of Blade：620mm
- Length of Blade：4270mm
- Min. Turning Radius：7.3m
- Operating Weight (Standard)：16.6ton
- Overall Dimensions：9080*2740*3310mm
- Transport Package：Nude
- Specification：170kw
- Origin：Shandong China
- HS Code：84292090
- Production Capacity：1000 Units Per Month
Description
Model
STG170C-8W3(IN)
STG190C-8
STG210C-8(DFC)
STG210C-8(WC)
STG230C-8
Engine Model
WP6G175E301
WP6G200E330
6CTAA8.3-C215
WP6G210E330
D07S3-231E0
Forward Speed
5/7/12/18/26/36km/h
6/10/13/21/27/42km/h
6/10/13/21/27/42km/h
6/10/13/21/27/42km/h
6/10/13/21/27/42km/h
Height of Blade
620mm
620mm
620mm
620mm
620mm
Length of Blade
3660mm
3660mm
3660mm
3660mm
4270mm
Max. Depth of Cut
630mm
630mm
630mm
630mm
630mm
Max. Lift Above Ground
450mm
450mm
450mm
450mm
450mm
Min. Turning Radius
7.3m
7.3m
7.3m
7.3m
7.3m
Operating Weight (Standard)
14.5ton
15.8ton
16.2ton
16.2ton
16.6ton
Overall Dimensions
8580*2740*3310
9080*2740*3310
9080*2740*3310
9080*2740*3310
9080*2740*3310
Peak Torque
760NM
900NM
980NM
900NM
925NM
Rated Power
129kW
147kW
160kW
154kW
170kW
Reverse Speed
5/12/26km/h
6/13/27km/h
6/13/27km/h
6/13/27km/h
6/13/27km/h
