• Model NO.：9W2451HD
• Transport Package：Standard Wooden Case
• Trademark：BY
• Origin：China
• Production Capacity：500 Tons , Month

Basic Info.

Model NO. 9W2451HD Transport Package Standard Wooden Case Trademark BY Origin China Production Capacity 500 Tons / Month

Product Description

1. Part No.: 9W2451HD
Description: D8, D9 Ripper Tip HD
Logo: BY or OEM
Color: Yellow or others

Applied Machine: Loader, Excavator
Applied Machine Models: D8, D8K, D8L, D8N, D8R, D9, D9H, D9N, D9R

Production Method: Casting
Material: Alloy steel
Chemical Component: Please contact with our sales to know details.
Hardness: HB 470-520
Impact: ≥ 15J
Tensile Strength: ≥ 1450Rm-N/mm²
Yield Strength: ≥ 1100Re-N/mm²

Matched Pin: 4T2479
Matched Retainer: 6J8814

Ripper tooth: D8, D8K, D8L, D8N, D8R, D9, D9H, D9N, D9R
Model Part No. Description Weight (kg) Pin Retainer
D8, D9 9W2451 Ripper Tip Short 15.4 4T2479 6J8814
9W2452 Ripper Tip Long 16.28 4T2479 6J8814
9W2451HD Ripper Tip HD 16.7 4T2479 6J8814


 Ripper Tooth: D9L, D10, D11
Model Part No. Description Weight (kg) Pin
D9, D10, D11 4T5501 Ripper Tip Short 20.25 3G0500
4T5501L Ripper Tip Short 24.34 3G0500
4T5502L Ripper Tip Long 26.98 3G0500
4T5502 Ripper Tip Long 27.18 3G0500
9W4551 Ripper Tip Short 42.5 6Y2443


Shank protector
Model Part No. Description Weight (kg)
D9, D10 9W8365 Shank protector 40.8
D11 9N4621 Shank protector 83

oth
Model Part No. Description Weight (kg) Bolt Nut
WA380 423-70-13114 Bolt on Tooth 15.94 09218-12219 01643-32260
341811-21140 Unitooth 13 N/A N/A
WA500 423-847-1140RP Unitooth 9.5 175-78-21740 N/A



Model Part No. Description Weight (kg) Pin
D65, D85 141-78-11253 ripper tooth 11.2 09244-02508
D85, D135, D155 175-78-31230 ripper tooth 13.1 09244-02508



Model Part No. Description Weight (kg)
/ 195-78-21320 shank protector 14

Any item you want not in this list, pls contact with us. Thanks!
We are also can make as your drawing or design.
