China Brand New 215HP Cheap Price Small Motor Grader Gr2153
Evangel Industrial (Shanghai) Co., Ltd.- After-sales Service：Online Service
- Warranty：1 Year
- Certification：ISO, CE
- Condition：New
- Application：Construct Work
- Transmission：Hydraulic
Base Info
- Model NO.：GR2153
- Walking Mode：Wheeled
- Type：Medium-sized Grader
- Specification：8900*2625*3420mm
- HS Code：8501109190
- Production Capacity：200
Description
Basic specification
GR2153
GR215A
Engine model
QSB6.7
6CTA8.3
Rated power/speed
164kW/2000rpm
160kW/2200rpm
Dimension(LxWxH)
8970×2625×3420mm
9180×2625×3300mm
Operating weight(Standard)
16500kg
16100kg
Performance specification
Travelling speed ,forward
5,8,11,19,23,38 km/h
5,8,11,19,23,38 km/h
Travelling speed ,reverse
5,11,23 km/h
5,11,23 km/h
Tractive force(f=0.75)
82KN
82KN
Max. gradeability
20%
20%
Tire inflation pressure
260 kPa
260 kPa
Working hydraulic pressure
16 MPa
16 MPa
Transmission pressure
1.3~1.8MPa
1.3~1.8MPa
Operating specification
Max. steering angle of front wheels
±50°
±17°
Max. lean angle of front wheels
±17°
±15°
Max. oscillation angle of front axle
±15°
15
Max. oscillation angle of balance box
15
±27°
Frame articulation angle
±27°
7.3m
Min. turning radius using articulation
7.3m
Biade
Maximum lift above ground
450mm
500mm
Maximum blade position angle
90°
28°-70°
Circle reversing rotation
360°
360°
Moldboard width X height
4270×610mm
4270×610mm
