• Specification：10-100tons
• Origin：China
• HS Code：8431499000
• Production Capacity：30000units,Month

Basic Info.

Specification 10-100tons Origin China HS Code 8431499000 Production Capacity 30000units/Month

Product Description

The hydraulic plate compactor is designed for effectively compacting soil in trenching, ground levelling, embankment construction, driving in and pulling out posts, sheet piling and other form works.

Hydraulic plate compactors come in many different designs with different accessories, though the major features are stable. The core of the machine is a heavy, flat plate that rests on the ground when the machine is off. The plate is driven or vibrated up and down with either gasoline or diesel engines.

The hydraulic compactors we provided is available to fit excavators from 4 to 40 tons.

As one of the largest and most professional manufacturer for the attachment, we can produce diverse types of attachment, such as ripper, hydraulic compactor, hydraulic grapple, hydraulic shear... Our provided attachment is manufactured by high precision CNC equipment which imported from Germany, Japan and South Korea. We use the best in class raw material which we purchase from the certified vendors of the market.

If you are interested in our products, please feel free to contact us for further information.

Technology parameter:


Model	Unit	WY04	WY06	WY08	WY10
Impulse Force	ton	4	6.5	11	15
Vibration Frequency	rpm/min	2000	2000	2200	2200
Oil Flow	L/min	50-80	80-110	120-170	120-170
Working Pressure	Bar	90-130	100-150	150-200	150-200
Bottom Measurement	mm	900*550	1160*700	1350*900	1500*1000
Weight	kg	550-600	750-850	900-1100	1100-1300
Carrier Weight	ton	4-9	10-16	17-25	30-40
