2019 Newest 220HP Pd220y Bulldozer Crawler Dozer with 6.4m3 Blade Capacity

Evangel Industrial (Shanghai) Co., Ltd.
  • Type：Universal Type
  • Transmission：Hydraulic Transmission
  • Walking Mode：Wheeled
  • Load and Unload Method：Front Discharge
  • Engine Power：147~515kw
  • Certification：CE, ISO9001: 2000

Base Info

  • Model NO.：pd220y
  • Condition：New
  • Color：Yellow
  • Transport Package：Nude Package
  • Specification：3921*2553*2745
  • Trademark：pengpu
  • Origin：China

Description

Machine model220Y-1Length×Width×Height (without Ripper)5750×3725×3575Operating Weight (t)25.5Flywheel HP (km/rpm)162/1800Track Gauge2000Ground Contact Length(mm) /Pressure(Mpa)2730/0.082Forward Speeds(km/h)3.6/6.5/11.2Reverse Speeds(km/h)4.3/7.7/13.2(Blade) Max. Drop below Ground (mm)Straight540/Angle535/U540(Ripper) Max. Dig below Ground (mm)Single666/3-shank555(Blade) Max. Lift above Ground (mm)1210(Ripper) Max Lift above Ground (mm)Single 598.3/3-shank 666Gradeability (º)30°Blade Capacity (m3)7.24/5.15/8.63/3.89EngineNT855-C280No. of Track Rollers (each side)6No. of Track Shoes (each side)38Track Width(mm)560Track Pitch(mm)216Blade TypeU/Straight, Landfill/AngleBlade Size Width×Height (mm)U 3800×1343/Straight 3725×1315/Landfill 3725×1702/Angle 4365×1055RipperSingle or 3-shank
