Factory Price Road Construction Machinery Rammer Compactor
Zhengzhou Hento Machinery Co., Ltd.- Output Voltage：220V, Customized
- Brand：Hento
- Weight：76Kg
- Dimension：61*52*97CM
- Transport Package：Fumigation-Free Wooden Case
- Specification：61*52*97CM
Base Info
- Model NO.：HT-HC90K
- Trademark：HENTO
- Origin：Henan, China
- Production Capacity：500sets,Month
Description
Basic Info.
Model NO. HT-HC90K Trademark HENTO Origin Henan, China Production Capacity 500sets/MonthProduct Description
Factory Price Road Construction Machinery Rammer Compactor1.Machine introduction of Factory Price Road Construction Machinery Rammer Compactor:
The products are widely used, adapted to the building, ground, subgrade, bridge pier, groove, wild, narrow site and so on environment construction, capable of large and medium-sized machinery was unable to complete tasks.The product has reasonable design, advanced structure, low noise, large compaction force, flexible operation, use safety, wide adaptation range, long life, high efficient multi-use, etc.
2.Technical parameters of Factory Price Road Construction Machinery Rammer Compactor:
1.Concrete cutter
| model | HT-HQ350 | HT-HQ400 | HT-HQ500 |
| Max Cutting Depth CM (in) | 9CM | 14CM | 18CM |
| Blade Size (in) | 350 | 350-400 | 350-500 |
| linear velocity of blade | 47-59m/s | 47-59m/s | 47-59m/s |
| Water Tank Capacity | 9L | 12L | 37L |
| N.W | 85KG | 100KG | 135KG |
| G.W | 110KG | 125KG | 160KG |
| Packing size: | 111*62*101CM | 111*62*101CM | 111*62*101CM |
2.Plate compator
| model | HT-HZ50 | HT-HZ60 | HT-HZ90 | HT-VC95 | HT-HZ115 | HT-HZ160 |
| Vibrating Force | 8KN | 10KN | 13KN | 13KN | 16KN | 30KN |
| Vibrating Frequency | 48Hz | 48Hz | 48Hz | 48Hz | 48Hz | 48Hz |
| Advancing Speed | 12m/min | 15m/min | 5~13m/min | 6~16m/min | 6~16m/min | 15m/min |
| Plate Size | 40CM×30CM | 50CM×37CM | 52CM×43CM | 66CM×44CM | 66CM×44CM | 70CM×50CM |
| N.W | 54KG | 60KG | 180KG/2SETS | 95KG | 115KG | 158KG |
| G.W | 59KG | 66KG | 210KG/2SETS | 120KG | 140KG | 165KG |
| Packing size | 70*42*63CM | 90*44*63CM | 124*52*75/2CM | 97*54*70CM | 97*54*70CM | 80*55*97CM |
3.Power trowel
| model | HT-DM600 | HTO-DM900 | HT-DM1000 |
| Diameter | 600mm | 900mm | 1000mm |
| Driving Speed(R.P.M) | 66-132r/min | 66-132r/min | 66-132r/min |
| QTY Of Blade | 4PCS | 4PCS | 4PCS |
| N.W | 70KG | 90KG | 95KG |
| G.W | 90KG | 110KG | 120KG |
| Packing size | 75*75*50CM | 103*103*50CM | 103*103*50CM |
4.Tamping Rammer
| model | HT-HC90K | HT-HC90K-2 |
| Ramming Force | 10KN | 15KN |
| Leap Height | 40-65mm | 40-65mm |
| Rammer Frequency | 450-650times/Min | 450-650times/Min |
| Advancing Speed | 10~13m/min | 10~13m/min |
| Rammer Plate Size | 300mm×330mm | 300mm×330mm |
| N.W | 76KG | 80KG |
| G.W | 85KG | 87KG |
| Packing size | 61*52*97CM | 61*52*97CM |
5.Contact information:
If you need further information, please contact us freely, we will do our best to cooperate with you.
