• Model NO.：XS123
• Certification：ISO9001: 2000
• Condition：New
• Transport Package：Container

ItemUnitParametersOperating weightkg (lbs)12000 (26667)Weight at Drumkg (lbs)6700 (14889)Weight at axlekg (lbs)5300 (11778)Static linear loadkg/cm (pli)31.5 (175.8)Driving speed ( gear I)km/h (mph)0-5 (0 -3.1)Driving speed ( gear II)km/h (mph)0-10.8 (0-6.75)Theoretical gradeability%45Minimum turning radiusmm (in)6800 (267.9)Tire specification 23.1-26-12G23TLply rating 12Air pressurekPa150-170Engine manufacturer  Type QSB4.5Emission EURO IIIRated powerkW (hp)97 (130)Rated speedrpm2300VoltageV24Vibrational frequencyHz (vpm)30/35 (1800/2100)Nominal amplitudeMm (in)1.8/0.9(0.071/0.035)Exciting forcekN (lbs)280/190(62944/42712)Engine oilL (gal)16.3(4.3)Fuel tankL (gal)240(63.4)Hydraulic tank capacityL (gal)240(63.4)CoolantL (gal)20(5.3)Front drum chamberL (gal)40(10.6)Front drum reducerL (gal)27(0.7)
