Ensign 3 Ton Mini Front End Wheel Loaders

Ensign Heavy Industries Co., Ltd.
  • Certification：ISO, CE
  • Condition：New
  • Rated Load：3-6t
  • Transmission：Hydraulic
  • Load and Unload Mode：Front Discharge
  • Walking Mode：Wheeled

Base Info

  • Type：Medium-sized Loader
  • Transport Package：Nude Packed
  • Specification：6868*2520*3255
  • Trademark：ENSIGN
  • Origin：China
  • HS Code：84295100
  • Production Capacity：10000 Units,Year

Description

Bucket capacity1.2~3.0(standard bucket 1.8m3)Total cycle time(lift, dump& lower)≤9.2sRated load3000kgDump height/Dump angle2960/45mm/ °Overall operating weight10500kgDump distance/Dump angle1040/45mm/ °Max. traction force≥105kNMin. ground clearance371.5mmMax. breakout force≥100kNWheel base2850mmGrade ability30°Wheel tread1850mmMin. turning radius(outer side of the bucket)5950mmDeparture angle30°Min. turning radius(outer side of the tire)
 5346mmSteering angle(left & right)38°Specifications:
1.0 Engine Details
  (1) Model:Weichai Deutz WP6G125E22 Engine
  (2) Engine Type:In-line arrangement,water-cooled,four-cycle diesel engine
  (3) Rated Power:92KW
  (4) Rated Speed:2300 r/min(rpm)
  (4) Fuel Consumption ration in
    Standard working condition:		225g/kw.H

2.0 Transmission System
  (1) Type:Planetary power shift
  (2) Torque converter type:Double turbine, 4 elements
  (3) Gears:2 forward, 1 reverse

3.0 Braking System
 (1) Service brake:Air-over-oil caliper disc
 (2) Parking brake:flexible shaft caliper disc

4.0 Steering system
(1) Type:Load sensing hydraulic
(2) Oil pump type:gear pump

5.0 Working device hydraulic system
(1) Hydraulic system pressure:16 Mpa
(2) Control type:Joystick
(3) Oil pump type:Gear pump

6.0 Tire
(1) Specification:17.5-25
(2) Tread pattern:L-3

7.0 Bucket
  (1) Bucket capacity:1.8 m3
  (2) Bucket type:Heavy-duty bolt on teeth
  (3) Rated Load:3000kg

Optional Configurations:
 Quick Hitch
  Joystick
  A/C
  Third function valve
  Longer arm
  Rops/Fops
  Tyre Chain
Optional Attachments:
 Rock Bucket
 Pallet/Grass Fork
 Grapple Forks/Wooden Forks
 Grapple Bucket
 Snow Bucket
 New Wooden Forks
 Hydraulic Snow Blade
 Sweeper
 Snow Blower
  4 In 1 Bucket
Ensign 3 Ton Mini Front End Wheel Loaders
FAQ:

Why choose us?
1). The quality is guaranteed due to strong technical support ,high quality component ,advanced production line and strict quality control system.
2). One-stop service with a large spare parts warehouse and professional service team .No matter where you are, you are guaranteed of Ensign' s warm reception, trustworthy and efficient professional services and persistent care.

Other terms:
1). Delivery: 30 days for normal orders
2). Price: We have price on basis FOB Qingdao and CIF or CFR your destination for your choice
3). Payment terms for first order:
-----T/T 30% down payment and balance before shipment
-----100% L/C at sight
4). Payment for long terms cooperation of good reputation partners, we have SINOSURE insurance for our VIP clients, and we can offer credit service after we familiar with each other. We are looking for partnership for long-term business
