Wolf Wl500 5 Ton Loading Bucket Loader Earth Moving Construction Loader with Transmission

Qingdao Zongjin Engineering Machinery Co., Ltd.
  • Warranty：1 Year
  • Certification：ISO, CE, Rops,Fops

Base Info

  • Model NO.：WL500
  • Condition：New
  • Rated Load：2ton
  • Transmission：Hydraulic
  • Load and Unload Mode：Front Discharge
  • Walking Mode：Wheeled
  • Type：Small Loader
  • Engine Model：Weichai Wd10g220e22
  • Rated Power：162kw
  • Rated Speed：2200rpm
  • Rated Bucket Capacity：3
  • Overall Size：8085*2855*3450
  • Wheel Base：3250mm
  • Wheel Thread：2250mm
  • Max.Breakout Force：170kn
  • Max.Dump Height：3140mm
  • Dump Distance：1250mm
  • Total Time：10.95s
  • Operating Weight：17100kg
  • Tyre：17.5-25
  • Optional Engine：Df Cummins 6CT8.3-C215 162kw
  • Transport Package：1 Set in 40gp
  • Specification：8085*2855*3450
  • Trademark：Wolf
  • Origin：Shandong, China
  • HS Code：84295100
  • Production Capacity：3000sets,Year
  • Package size per unit product：7180.00cm * 2855.00cm * 3450.00cm
  • Gross weight per unit product：17100.000kg

Description




Transmission systemTorque converterYJ375Gearbox modePlanetaryGear shift2 forward shift  1reverse shiftMaximum speed38km/hWheel base (mm)3200mmWheel tread2250mmTyreType specification23.5-25
