• Model NO.：HQ610
• Size：Small-Scale
• Certification：CE, ISO9001: 2000, SGS, Rops&Fops
• Condition：New
• Engine：Perkins
• Max Loading Weight：1600kg
• Lamp：E4 Standard
• Transport Package：3 Units in One Hq40 Feet Container
• Specification：CE, ISO, SGS, ROPS&FOPS
• Trademark：Haiqin
• Origin：Shandong, China
• HS Code：84295100
• Production Capacity：9000 Units , Year

Basic Info.

Model NO. HQ610 Size Small-Scale Certification CE, ISO9001: 2000, SGS, Rops&Fops Condition New Engine Perkins Max Loading Weight 1600kg Lamp E4 Standard Transport Package 3 Units in One Hq40 Feet Container Specification CE, ISO, SGS, ROPS&FOPS Trademark Haiqin Origin Shandong, China HS Code 84295100 Production Capacity 9000 Units / Year

Product Description

1, Advantage of minilader HQ610:

(1) Perkins Engine.
The engine is the heart of every machine. To reflect the importance of this central component justice, the HQ610 is powered by a Perkins engine type 404D-22 with four cylinders in series. This engine is characterized by its low fuel consumption, exhaust emission values in accordance with its Tier III and his Lanlebigkeit.
(2) production standards:
For quality assurance, the wheel loader as well as the working conditions, the production of each batch is run from the start on site.
(3) The counter weight increased, it can lift max1600kg.

2, Specifications:

Operating weight: 3200kg
Overall size: 5000*1650*2620 mm
Max. Turning angle: 35 degree
Engine model: Perkins engine 404D-22 ( Yanmar or Xinchai engine for option )
Rated power: 37Kw
Rated Load capacity: 1200 kg
Max load capacity: 1600kg
Bucket capactiy: 0.5-0.8 cubic meter
Wheelbase: 1870 mm
Mini turning radius: 4100mm
Mini ground clearance: 240 mm
Lifting height: 3500 mm
Unload height: 2920 mm
Unloading distance: 1080 mm
Raising time: 4s
3 cycles summed up time: 9 S
Max. Breakout force: 42 Kn
Drive mode: 4x 4 WD
Tires Standard: 12-16.5 / 31*15.5-15
Walking speed: 17-22 km/h
