• Model NO.：YN966
• Load and Unload Method：Front Discharge
• Color：Yellow
• Scraper Type：Front Loader
• Transport Package：Naked
• Trademark：YINENG
• HS Code：84295100
• Production Capacity：300 Units,Month

Basic Info.

Model NO. YN966 Load and Unload Method Front Discharge Color Yellow Scraper Type Front Loader Transport Package Naked Trademark YINENG HS Code 84295100 Production Capacity 300 Units/Month

Product Description

Rated load: 6000kg
Overall weight: 19200kg
Rated capacity: 3.5m3
Max. Tractive force170KN
Max. Breakout force≥ 190KN
Max. Grade ability: 30°
Max. Dumping height: 3100mm
Max. Dumping reach: 1250mm
Overall dimension: L x W x H8160X3070X3400mm
Min. Turning radius: 6630mm

Engine
Model: Shangchai CAT SC11CB240.1G2B1
TypeInline/Turbocharged/: Water colling
No. Of cylinder-bore/stoke: 6-121X152mm
Rated power: 175kw-2200r/min
Max. Torque: 950N. M
Min. Fuel-consume ratio≤ 215g/kw. H

Transmission ModelL: WG180 made by Hangzhou Advance Gearbox Group
Gear shift: 4 forward, 3 reverse.
Electronic control gear shift
Max. Speed: 38km/h

Drive axle: Main reducing spiralBevel gear grade 1 reduction
Decelerating model: Planetary reduction, grade 1.
Wheel base: 3200mm
Wheel tread: 2250mm
Min. Ground clearance: 510mm

Hydraulic system
System working pressure: 18MPa
Boom lifting time: 6.0+0.2s
Total time: 12+0.5s
Fuel tank capacity: 300L
Leveling automatically: Yes

Break system
Service brake: Air over hydraulic disc brake on 4 wheels
Parking brake: Expand hoof type

Tyre
Type: 26.5-25
Front tyre pressure: 0.4Mpa
34Rear tyre pressure: 0.35Mpa
