Cheapest Price Changlin 27ton Tire Roller 8272-5 with 2718mm Roller Width
Evangel Industrial (Shanghai) Co., Ltd.- Type：Road Roller
- Working Method：Vibration
- Engine Type：Diesel Engine
- Travel Speed：40cm,s
- Certification：EPA, CS, CE, RoHS, ISO 9001:2000, ISO 9001:2008
- Condition：New
Base Info
- Model NO.：8272-5
- Transport Package：Nude Package
- Specification：4945*2844*3393mm
- Trademark：changlin
- Origin：China
Description
Top quality Changlin 27ton pneumatic tyre tire road roller 8272-5 in stock
Product DescriptionThe road roller coming in the model of 8272-5 is a kind of pneumatic roller. It adopts eleven-wheel vibration, which brings high compacting quality. It is equipped with two sets of sprinkling system. By adjusting the capacity of ballast water, the ground pressure can be changed correspondingly.
Due to these advantages, the road roller has found applications in compaction of cohesive or non-cohesive base and sub-base layers of various materials. For example, it can be used to compact asphalt in the construction of roads.
Overall Dimension
1
Length
4945mm
2
Width
2844mm
3
Height(To the top of the cab)
3393mm
4
Wheel base
3800mm
Main Technical Specification
1
Max Operating weight
27000kg
2
Min Operating weight
14800kg
3
Max. ballast water
2100 kg
4
Average ground press
260-435kPa
5
Min. ground clearance
270mm
6
Roller width
2718mm
7
Gradeability
≥20%
8
Min. turning radius(Outside of rear wheel)
≤9000mm
