• Model NO.：WRC
• Travel Speed：40cm,s
• Centrifugal Force：40KN
• Certification：ISO 9001:2000
• Condition：New
• Tandem Vibratory Rolle：Tandem Roller
• Tandem Compactor：Double Drum Roller
• Transmission：Hydraulic
• Operation Weight：8ton
• Engine：Cummins
• Transport Package：in Container
• Specification：ISO
• Trademark：world
• Origin：China
• HS Code：84295100
• Production Capacity：2000PCS,Year

Basic Info.

Model NO. WRC Travel Speed 40cm/s Centrifugal Force 40KN Certification ISO 9001:2000 Condition New Tandem Vibratory Rolle Tandem Roller Tandem Compactor Double Drum Roller Transmission Hydraulic Operation Weight 8ton Engine Cummins Transport Package in Container Specification ISO Trademark world Origin China HS Code 84295100 Production Capacity 2000PCS/Year

Product Description

Tandem Vibratory Roller

Features:
1)Full hydraulic two wheel drive and vibration.
2)Double frequency double vibration system.
3)Hydraostatic center articulated steering, patented crab mechanism.
4)Cabin with air conditioner, comfortable and spacious, flexible steering seat.
5)Cabin can be turned on one side for easy maintenance.
6)Fork type frame, good hold-down property.
7)American Sauer or Germany Rexroth hydraulic pump and vibration motor.

MODEL		WRC208	WRC210	WRC212	WRC214
Operating mass	kg	8000	10000	12000	14000
Front axle load	kg	4000	5000	6000	7000
Rear axle load	kg	4000	5000	6000	7000
Static linear load	N/cm	231	238	286	333
Crabwise movement distance	mm	170	170	170	170
Vibration frequency	Hz	45/50	45/50	40/46	40/46
Vibration amplitude	mm	0.67/0.34	0.67/0.34	0.8/0.4	0.8/0.4
Centrifugal force	kN	90x2/69x2	90x2/69x2	160x2/90x2	160x2/90x2
Travel speed	km/h	0-15	0-15	0-12.7	0-12.7
Grade ability	%	25	25	30	30
Turning angle		35	35	35	35
Ground clearance	mm	324	324	324	324
Turning radius	mm	6000	6000	7000	7000
Vibration drum transverse swing angle		8	8	8	8
Overall length	mm	4558	4558	5060	5060
Overall width	mm	1840	1840	2250	2250
Overall hieght	mm	2830	2830	3300	3300
Drum width	mm	1730	1730	2100	2100
Drum diameter	mm	1150	1150	1350	1350
Drum rim thickness	mm	20	20	20	20
Wheel base	mm	3217	3217	3717	3717
Diesel model		Cummins 4BT3.9	Cummins 4BT3.9	Cummins 6BT5.9	Cummins 6BT5.9
Diesel power	kW	75	75	110	110
Diesel speed	r/min	2400	2400	2300	2300
Water tank capacity	L	2X400	2x400	2X600	2X600
Fuel tank capacity	L	110	110	174	174
Hydraulic tank capacity	L	75	75	75	75
